Meadley Plus
Meadley Plus is the most versatile high bay in the Meadley family, combining high efficiency with multiple selectable settings for maximum on-site flexibility. Wattage, colour temperature and beam angle can all be adjusted via dip switches, allowing installers to fine-tune lighting levels without changing the fitting. With plug-and-play sensors, emergency compatibility and robust industrial construction, Meadley Plus provides a highly adaptable lighting solution for warehouses, factories and logistics environments.
Class:
1
Operating Temperature:
-30ºC - 50ºC
(0ºC - 30ºC Emergency)
Ingress Protection:
IP65
Wattages Available:
60W/80W/100W, 90W/120W/150W, 120W/160W/200W, 145W/190W/240W
Beam Angle:
90º/120º
Kelvin: 3CCT Selectable
4000K 5000K 6000K
Lm/W:
170
Features
Triple Wattage Selection
Multi-power settings allow installers to optimise light output and energy consumption on site.
Selectable Beam Angles
90° or 120° optics adjustable via dip switch for focused or wide distribution.
Plug & Play Smart Controls
Compatible with microwave, PIR and truSmart sensors via Zhaga socket.
High Efficiency Performance
Up to 170 lm/W delivering powerful illumination with reduced energy use.
Industrial Grade Reliability
IP65 / IK08 aluminium housing with up to 100,000 hour lifetime.
3CCT Selectable
Choose between 4000K, 5000K or 6000K to suit different industrial environments.
